Wire Mesh Conveyor Belt chain driven metal mesh belt with conventional weave offering unobstructed openings for product transfer

Name: Wire Mesh Conveyor Belt chain driven metal mesh belt with conventional weave offering unobstructed openings for product transfer
Brand: Anping County Comesh Filter Co.,Ltd
SKU: CO-LO
Price: 34.99 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Comesh

Certification: FDA

Model Number: CO-LO

Payment & Shipping Terms

Minimum Order Quantity: 10 meters

Price: USD 5.99-65.99per meter

Packaging Details: wooden box

Delivery Time: 5-8 working days

Payment Terms: L/C, T/T

Supply Ability: 1000 meters per week

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                    chain driven wire mesh conveyor belt, metal mesh belt with conventional weave, wire conveyor belt for product transfer


Belt Length:	Customizable	Structure:	Flat Wire, Balanced Weave, Etc.
Key Worrds:	Metal Wire Mesh Conveyor Belt	Wire Diameter:	0.5mm - 5mm
Tooling Pitch:	8.2mm 8.5mm	Other Keyword:	Spiral Conveyor Belt
Ceritificate:	FDA Certificate / ISO 9001:2008	Hot Search:	Wire Mesh Conveyor Belt
Tensile Strength:	Up To 1000 N/mm²	Diameter:	0.5-5mm
Hole:	Customzied	Advantage:	Pressure Resistance
Applications:	Casting	Style:	Chain Conveyor Belt

Belt Length:	Customizable
Structure:	Flat Wire, Balanced Weave, Etc.
Key Worrds:	Metal Wire Mesh Conveyor Belt
Wire Diameter:	0.5mm - 5mm
Tooling Pitch:	8.2mm 8.5mm
Other Keyword:	Spiral Conveyor Belt
Ceritificate:	FDA Certificate / ISO 9001:2008
Hot Search:	Wire Mesh Conveyor Belt
Tensile Strength:	Up To 1000 N/mm²
Diameter:	0.5-5mm
Hole:	Customzied
Advantage:	Pressure Resistance
Applications:	Casting
Style:	Chain Conveyor Belt

Product Description

Chain-Driven Metal Mesh Belts

Chain-driven metal mesh belts should be considered whenever timing, transfer, and/or positive belt drive are important … in cases such as travel-up inclines, under heavy loads, for long distances, through quenching liquids, cooking oils, or other slippery conditions.
Chain-driven belts are also the only belts that are self-supporting. They can provide efficient operation in applications where friction-driven belts would not be desirable. Any mesh can be used in a chain-driven construction, but the selection is made on the basis of what is needed to support the product.
Balanced weave should be given first consideration, as it is economical and appropriate for most conditions. Gratex weave provides a closer mesh, while a Duplex weave is a close mesh that also provides strength and a straight-through opening. A conventional weave provides unobstructed openings.

Specification

product name	Stainless Steel Wire Mesh Belt
Application	Bakery Ovens, Food Equipment, Belt Con
Transport Package	Wooden Box
Cross Wire	1mm,1.2mm,1.5mm,1.8mm,2mm
Rod Wire	2-6mm
Belt Wide	0.5-2m
Voltage	220V 380V
Work Temp	-40celsius ~ 90celsius

Chain Selection

Chains are normally selected according to the strength and speed required. The most frequently used types of chain for metal mesh conveyors are roller chain, employed for most room-to-medium temperature applications, and pintle chain which is recommended for heavier loads and higher temperatures.
Due to the important and specialized nature of the applications requiring these products, each inquiry is reviewed thoroughly. Our goal is to supply the most suitable belt for your specific application. We strive to provide solutions for each situation, assuring value for our customers. Our engineers and technical support group are involved in every specialty belt inquiry and order.

Application

Typical Applications

In food processing, chain-driven belts are used in washing, drying, cooking, freezing, dewatering, and blanching operations. In other applications, metals, electronic parts, chemicals, ceramics, leather, lumber, textiles, rubber, and many other products are moved through a host of processes where the positive drive is needed.
