High Temperature Resistant 316L Stainless Steel Balanced Weave Wire Mesh Conveyor Belt For Industrial Furnace Equipment

Name: High Temperature Resistant 316L Stainless Steel Balanced Weave Wire Mesh Conveyor Belt For Industrial Furnace Equipment
Brand: Anping County Comesh Filter Co.,Ltd
SKU: BW-316L-2000
Price: 41.00 USD
Availability: InStock

Product Details

Place of Origin: Hebei, China

Brand Name: COMESH

Certification: ISO 9001:2015, SGS

Model Number: BW-316L-2000

Payment & Shipping Terms

Minimum Order Quantity: 3 Meters

Price: USD 28-55 / Meter

Packaging Details: Rolled on reinforced steel spool with VCI anti-rust paper, export-grade fumigated wooden crate

Delivery Time: 7-10 working days for stock, 20-30 days for production

Payment Terms: T/T,Western Union,L/C

Supply Ability: 500 Meters per Month

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                    316L stainless steel conveyor belt, high temperature resistant wire mesh belt, industrial furnace conveyor belt


Weave Type:	Balanced Weave (Compound Balance)	Material:	SS316L (AISI 316L / 1.4404) Stainless Steel
Wire Diameter:	1.5mm / 2.0mm / 2.5mm / 3.0mm / 3.2mm	Belt Width Range:	400mm — 4000mm
Mesh Pitch:	4mm / 6mm / 8mm / 12mm / 16mm / 20mm / 25mm	Open Area Ratio:	45% — 65%
Working Temperature:	-40°C To 600°C	Load Capacity:	Up To 120 Kg/m²
Edge Type:	Welded Edge / Chain Drive / Reinforced	Application:	Furnace, Heat Treating, Glass Tempering, Sintering

Weave Type:	Balanced Weave (Compound Balance)
Material:	SS316L (AISI 316L / 1.4404) Stainless Steel
Wire Diameter:	1.5mm / 2.0mm / 2.5mm / 3.0mm / 3.2mm
Belt Width Range:	400mm — 4000mm
Mesh Pitch:	4mm / 6mm / 8mm / 12mm / 16mm / 20mm / 25mm
Open Area Ratio:	45% — 65%
Working Temperature:	-40°C To 600°C
Load Capacity:	Up To 120 Kg/m²
Edge Type:	Welded Edge / Chain Drive / Reinforced
Application:	Furnace, Heat Treating, Glass Tempering, Sintering

Product Description

High Temperature Resistant 316L Stainless Steel Balanced Weave Wire Mesh Conveyor Belt For Industrial Furnace Equipment

Engineered for extreme industrial environments, our balanced weave 316L stainless steel wire mesh conveyor belt delivers outstanding high temperature resistance up to 600°C. The balanced weave construction features interlocking right-hand and left-hand wire spirals for a tight, flat mesh surface — the ideal choice for heat treating furnaces, annealing lines, and heavy-duty industrial conveying where standard belts fail.

Key Features

316L Stainless Steel Grade: Premium low-carbon variant with molybdenum addition — superior resistance to pitting, chloride corrosion, and intergranular attack at elevated temperatures
Balanced Weave Construction: Tight interlocking spiral wires produce an exceptionally flat, dense mesh surface capable of carrying small components without product fall-through
High Temperature Rated: Continuous operation at 600°C with excellent dimensional stability — no warping, stretching, or oxidation in harsh furnace atmospheres
Heavy Duty Design: Available with reinforced chain-driven edges and heavy-gauge wire up to 3.2mm diameter for conveying loads exceeding 100 kg/m²
Custom Engineered: Belt width up to 4000mm, custom mesh pitch from 4mm to 25mm, welded or mechanical joint options for any installation configuration

Technical Specifications

Material Grade	SS316L (AISI 316L / 1.4404) Stainless Steel
Weave Type	Balanced Weave (Compound Balance)
Wire Diameter	1.5mm / 2.0mm / 2.5mm / 3.0mm / 3.2mm
Belt Width	400mm — 4000mm (Customizable)
Mesh Pitch	4mm / 6mm / 8mm / 12mm / 16mm / 20mm / 25mm
Open Area Ratio	45% — 65%
Working Temperature	-40°C to 600°C (Continuous)
Load Capacity	Up to 120 kg/m² (with 3.2mm wire)
Edge Finish	Welded Edge / Chain Driven with Sprocket / Reinforced Edge
Certification	ISO 9001:2015, SGS Material Test Report Available

Applications

Heat treating furnaces — annealing, tempering, quenching conveyor lines
Brazing and soldering ovens — continuous high-temperature processing
Glass tempering lehrs — flat glass and automotive glass heat treatment
Powder metallurgy sintering furnaces — metal powder compaction and sintering
Chemical processing — corrosive atmosphere conveying at elevated temperatures
Automotive parts heat treatment — gears, springs, bearing races

Need a heavy-duty balanced weave 316L conveyor belt for your furnace or heat treating line? Send us your operating temperature, belt dimensions, and load requirements — we engineer the solution.
