Food Industry 0.2m Width FDA Chain Mesh Conveyor Belt For Drying

Brand Name:	COMESH
Model Number:	CM-CB324
MOQ:	5m
Price:	USD65-120 per meter
Payment Terms:	D/A, D/P, T/T, Western Union,
Supply Ability:	500m per week

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

FDA

Material:

Stainless Steel 304 316

Width:

0.2m To 4m

Length:

Customized

Wire Diameter:

1.0mm 1.2mm 1.5mm 2.0mm

Spiral Pitch:

3mm-20mm

Rod Diameter:

4mm-20mm

Rod Pitch:

5 To 30 Mm

Chain Pitch:

19.05mm, 25.4mm, 31.75mm, 38.1mm, 50.8mm, 76.2mm

Packaging Details:

PP bag inside, and then wooden case outside

Highlight:

0.2m width chain mesh conveyor belt

width 0.2m chain mesh conveyor belt

FDA drying chain mesh conveyor belt

Product Description

Food Industry 304 Stainless Steel Chain Wire Mesh Conveyor Belt for Drying

1. Description :

Food Industry 304 Stainless Steel Chain Wire Mesh Conveyor Belt for Drying can be customized as per your your requirement. Pls advise the details in the following drawing before making best offer. If you can not confirm them, pls advise the width, length, loading weight, the size of item which are conveyed and working temperature, so that we provide you with the available specification and price.

Food Industry 0.2m Width FDA Chain Mesh Conveyor Belt For Drying 0

Food Industry 0.2m Width FDA Chain Mesh Conveyor Belt For Drying 1

2. Specification :

Material	stainless steel 304
Width	0.2-4.0m
Length	customized
Spiral wire diameter	0.5-5.0mm(usual 1.0-3.0mm)
Rod diameter	4.0-12.0mm (common 6.0mm and 8.0mm)
Spiral pitch	3.0-20mm
Cross wire pitch	5.0-50mm
Driven type	sprockets and chains

3. Applications :

Food industry: often used in light weight products processing - frying, freezing, heating, cooling, cooking, drying, baking, coating, enrobing and sterilization for desserts, pizza, vegetables, bread, flour cakes, meat, fish, candy, potatoes, biscuits, chocolate, nuts, fruit, etc. Like chocolate enrobing, battering and breading, freezing for seafood processing, frying chickens, cooling wafer after coating, pizza baking.
Electronics industry: printed circuit board required minimum contact support, melting, sold or drying welding.
Caps making industry: drying for drop plastic

4. Available materials :

1) AISI 314 (1150°C)
2) SUS 310S (1090°C)
3) SUH 330 (1150°C)
4) SUS 304 (870°C)
5) Super alloy Cr20Ni80 (1250°C) electrical furnace wire
6) SUS 321 (750°C)
7) SUS 410 (700°C)
8) SUS 430 (700°C)
9) Various metal materials as per your requirements

Food Industry 0.2m Width FDA Chain Mesh Conveyor Belt For Drying 2

5. Packing & Delivery :

6. Company Information :

Anping County Comesh Filter Company, founded in 1986 in Anping China, and now is a leading manufacturer and supplier of high-quality filtration media, and offers the industry's broadest range of products:
