| Style: | Link Belt | Material: | 304,310,316, |
|---|---|---|---|
| Surface Treatment: | Galvanized Or PVC Coated | Length: | Request |
| Width: | Request | ||
| High Light: | conveyor chain belt,stainless steel mesh conveyor belt |
||
SUS304,310,316 Stainless Steel Wire Mesh Conveyor Belt With Link Belt For Heavy
Description of wire mesh conveyor belt
Usually this belt is called eye link belt.Wires are formed into eye-links and joints with rods.With opening is increased collars or by spot welding.
Advantages of eye link belt
1.Positive sprocket drive ensures stable running,
2.Belt has smooth surface and unstable products cna be carried,
3.Washing is easy
4.Aperture can be increased for high air permeability and dyration capacity
5.Reinforcement plate links are made for heavy load and high speed.
Specifications of eye link belt
| Specifications | Weight (kg/m2) |
| R2-6 - 63.5-13.8-3.0 | 32.9 |
| R2-5.2-63.5-12.0-2.6 | 32.9 |
| R2-4.6-50.8-8.0-2.3 | 24.2 |
| R2-4.0-50.8-10.0-2.0 | 27.6 |
| R2-3.2-50.8-8.0-1.6 | 17.1 |
| R2-5.2-50-6.0-2.6 | 21.4 |
| R2-4-50-6.0-2.0 | 18.0 |
| R2-5.2-50-5.0-2.6 | 18.8 |
| R2-5.2-38.1-7.0-2.6 | 29.2 |
| R2-4-38.1-8.0-2.0 | 26.9 |
| R2-3.2-38.1-6.0-1.6 | 17.4 |
| R2-2.4-38.1-8.0-1.2 | 18.3 |
| R2-4-31.75-7.0-2.0 | 27.7 |
| R2-2.4-25.4-6.0-2.0 | 13.2 |
| R2-2.4-25.4-6.0-2.0 | 25.5 |
| R2-2.4-31.75-5.0-1.2 | 15.6 |
| R2-4-25.0-5.0-2.0 | 22.2 |
Please tell me the specifications according to the following drawing,
Unless this belt ,we have many kinds of conveyor belt
We also kinds of sprocket.
