White 64T 55 Micron Polyester Screen Printing Mesh for PCBs

Brand Name:	PFM
Model Number:	PFM-Hel
MOQ:	30meter
Price:	Negotiable
Payment Terms:	D/A, L/C, D/P, T/T, Western Union, ，Trade assurance,Paypal
Supply Ability:	3000meters per week

Detail Information

Product Description

Detail Information

Place of Origin:

Hbei,China

Certification:

FDA

Product Name:

Yellow 64T - 55 Micron Polyester Screen Printing Mesh For Printed Circuit Boards Printing

Thread Diameter:

55 Micron

Mesh/inch:

160

Applications:

Printed Circuit Boards Printing

Color:

White

Packaging Details:

plastic bag inside, carton case outside,5-10rolls in one carton

Highlight:

screen printing mesh roll

monofilament polyester mesh

Product Description

Yellow 64T - 55 Micron Polyester Screen Printing Mesh

Product Specifications

Attribute	Value
Thread Diameter	55 micron
Mesh Count (per inch)	160
Mesh Count (per cm)	64
Opening Size	101 micron
Color	White/Yellow
Available Widths	115cm, 127cm, 136cm, 145cm, 157cm, 165cm, 188cm, 220cm (Max width: 3.65m)
Primary Application	Printed Circuit Boards (PCB) Printing

Key Features

High tension threshold and breaking point
High modulus, low elongation monofilament polyester yarn
Resistant to chemicals, abrasion, heat and moisture
Minimal tension loss during stretching process
Improved registration due to stable fabric tension
Excellent antistatic properties
No surface treatment required

Applications

This polyester screen printing mesh is widely used in:

Printed Circuit Board (PCB) printing
Textile and T-shirt printing
Ceramic and glass printing
Industrial printing applications

Technical Specifications

Count (inch)	Count (cm)	Diameter (µm)	Opening (µm)	Open Area (%)	Thickness (µm)	Volume (cm³/cm²)	Max Tension (N/cm)
160	64	55	101	42	98	41	25-30

Production Process

Packaging Details

Mesh rolls in PP bags
2-12 rolls per carton
Waterproof outer packaging
Reinforced with package belts

Ordering Information

Minimum Order Quantity (MOQ): Typically 30 meters (smaller quantities may be available upon request)

Samples: Free samples up to 2 meters available (customer pays shipping)

Mesh Selection Guide

20-40 mesh: Ideal for glitter inks requiring open mesh
60 mesh: Suitable for smaller glitter and shimmer inks
80 mesh: Excellent for high-density printing and foil adhesive
110-120 mesh: Perfect for thick inks and maximum coverage
155-200 mesh: General purpose textile printing with good detail
230-305 mesh: High-end fine detail and halftone printing

Customer Support

Pre-Sale Services:

Technical consultation and support
Sample testing
Factory visits

After-Sale Services:

Prompt shipment tracking
Usage guidance
Quality guarantee and replacement policy
