Food Grade Nylon Filter Mesh With White Color For Paint Filtration
Description:
White nylon yarn is also called nylon blended, the material for the food grade nylon 66, non-toxic, odorless. High strength, large elongation, excellent flexibility. Strong, good wear resistance, home all the first fiber.
Features of nylon filter mesh
Specification of nylon filter mesh
Woven mesh specifications are the mesh size, wire diameter, aperture, width, etc., nylon network as a wide variety, use different, so the specifications are not the same, in general, for the screening of the mesh with a mesh of 60 -420 mesh, wire diameter and mesh have a corresponding ratio between the parameters, the smaller the smaller the diameter of the smaller diameter; for fisheries fishing on the larger mesh, wire diameter is also larger
| Fabric number |
Mesh count |
Thread diameter | Mesh opening |
Open surface |
Fabric thickness |
Weight | ||
| NO. | Mesh/cm | Mesh/inch | micron | micron | % | micron | g/m2 | |
| JPP4 | 4 | 10 | 550 | 1950 | 61 | 950 | 262 | |
| JPP5 | 5 | 12 | 500 | 1500 | 56 | 850 | 271 | |
| JPP6 | 6 | 16 | 400 | 1267 | 58 | 780 | 208 | |
| JPP7 | 7 | 18 | 350 | 1079 | 57 | 675 | 186 | |
| JPP8 | 8 | 20 | 350 | 900 | 52 | 685 | 212 | |
| JPP9 | 9 | 24 | 250 | 860 | 60 | 455 | 145 | |
| JPP10 | 10 | 25 | 300 | 700 | 49 | 576 | 195 | |
| JPP12 | 12 | 30 | 250 | 583 | 49 | 470 | 162 | |
| 12 | 30 | 300 | 533 | 41 | 585 | 234 | ||
| JPP14 | 14 | 35 | 300 | 414 | 34 | 595 | 273 | |
| JPP16 | 16 | 40 | 200 | 425 | 46 | 370 | 139 | |
| 16 | 40 | 250 | 375 | 36 | 485 | 217 | ||
| JPP20 | 20 | 50 | 150 | 350 | 49 | 375 | 98 | |
| 20 | 50 | 200 | 300 | 36 | 385 | 173 | ||
| JPP24 | 24 | 60 | 150 | 267 | 41 | 285 | 117 | |
| JPP28 | 28 | 70 | 120 | 237 | 44 | 215 | 87 | |
| JPP30 | 30 | 76 | 120 | 213 | 41 | 225 | 94 | |
| JPP32 | 32 | 80 | 100 | 213 | 46 | 165 | 69 | |
| JPP36 | 36 | 90 | 100 | 178 | 41 | 178 | 78 | |
| JPP40 | 40 | 100 | 100 | 150 | 36 | 190 | 87 | |
| JPP43 | 43 | 110 | 80 | 152 | 43 | 135 | 60 | |
| JPP48 | 48 | 120 | 80 | 130 | 38 | 145 | 62 | |
| JPP56 | 56 | 140 | 60 | 120 | 44 | 85 | 44 | |
| JPP59 | 59 | 150 | 60 | 110 | 42 | 98 | 46 | |
| JPP64 | 64 | 160 | 60 | 100 | 37 | 105 | 50 | |
| JPP72 | 72 | 180 | 50 | 90 | 41 | 82 | 39 | |
| JPP80 | 80 | 200 | 50 | 75 | 36 | 90 | 43 | |
| JPP100 | 100 | 250 | 40 | 60 | 36 | 65 | 35 | |
| JPP120 | 120 | 305 | 40 | 43 | 25 | 70 | 42 | |
| JPP130 | 130 | 330 | 40 | 37 | 23 | 75 | 45 | |
Application of nylon filter mesh
1. used in refrigeration air conditioning equipment, air cleaners and air purification equipment and engineering dust filter early use.
2. Office buildings, conference rooms, hospitals, shopping malls, gymnasiums, airports and other large civil building ventilation system; general factory centralized ventilation and air conditioning system; clean room centralized ventilation air conditioning system in the primary filter
