DFP39 100 Mesh Polyester Screen Printing Mesh for Electronics

Brand Name:	PFM
Model Number:	PFM-W
MOQ:	5meters
Price:	Negotiable
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, ,Paypal
Supply Ability:	2000meters per week

Detail Information

Place of Origin:

Hebei,China

Certification:

FDA

Model:

DFP 39

Usage:

For Electronic Printing

Color:

White

Feature:

High Accuracy

Width:

1.27m

Sample:

1m Is Free

Packaging Details:

Plastic bag inside and caton box outside,or cut into small pieces then put them into plastic bags.

Highlight:

Product Description

DFP100 Mesh Polyester Screen Printing Mesh With High Accuracy For Electronic

Product Specifications

Key Features

High tension: Excellent tension stability with low screen tension, resulting in high-precision printing with excellent off-grid and ink stripping properties.
High precision: Capable of reaching 500 mesh/cm with tightly controlled screen thickness, opening, and wire diameter tolerances.
High wear resistance: Made from premium fibers with specially treated surfaces to withstand high-pressure friction and ensure durability.

Technical Specifications

Model	Mesh Count (mesh/inch)	Thread Diameter (Micron)	Mesh Opening (Micron)	Open Surface (%)	Fabric Thickness (um)	Weight (G/m2)
DFP30	76	55*2	223	45	100	45
DFP33	84	55*2	192	40	100	50
DFP36	90	55*2	167	36	105	54
DFP39	100	55*2	146	32	105	58
DFP42	107	45*2	148	39	77	42
DFP46	120	45*2	127	34	78	46
DFP54	137	45*2	94	26	80	54
DFP58	147	39*2	94	30	74	44
