DFP100 Mesh Polyester Screen Printing Mesh With High Accuracy For Electronic

DFP100 Mesh Polyester Screen Printing Mesh With High Accuracy For Electronic
DFP100 Mesh Polyester Screen Printing Mesh With High Accuracy For Electronic DFP100 Mesh Polyester Screen Printing Mesh With High Accuracy For Electronic

Large Image :  DFP100 Mesh Polyester Screen Printing Mesh With High Accuracy For Electronic

Product Details:
Place of Origin: Hebei,China
Brand Name: PFM
Certification: FDA
Model Number: PFM-W
Payment & Shipping Terms:
Minimum Order Quantity: 5meters
Price: Negotiable
Packaging Details: Plastic bag inside and caton box outside,or cut into small pieces then put them into plastic bags.
Delivery Time: within 8days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, ,Paypal
Supply Ability: 2000meters per week
Detailed Product Description
Model: DFP 39 Usage: For Electronic Printing
Color: White Feature: High Accuracy
Width: 1.27m Sample: 1m Is Free
High Light:

screen printing fabric mesh

,

monofilament polyester mesh

                  DPP180mesh Polyester Screen Printing Mesh With High Accuracy For Electronic



Features of polyester screen printing mesh

  • High tension: good tension stability of the screen tension is low; due to high tension, small mesh distance, off-grid and ink stripping excellent, can get high-precision, high-quality printing results. At the same time, the tension in the printing process to maintain a good stability, more to ensure the quality of printing and screen version of the service life.
  • High precision: high head can reach 500 mesh / cm, screen thickness, opening, wire diameter error control within a small range, is a high-precision line printing and dot printing excellent choice.
  • High wear resistance: the use of high-quality fiber to do raw materials, wire mesh surface after special treatment, can withstand high pressure friction times, so that the screen has a high degree of security and resistance to printing times.

Specifications



Specifcition

Mesh count

 mesh/inch

Thread diameter

      Micron

Mesh opening

    micron

Open surface

     %

Fabric thickness(um)

Weight

  G/m2

DFP30 76 55*2 223 45 100 45
DFP33 84 55*2 192 40 100 50
DFP36 90 55*2 167 36 105 54
DFP39 100 55*2 146 32 105 58
DFP42 107 45*2 148 39 77 42
DFP46 120 45*2 127 34 78 46
DFP54 137 45*2 94 26 80 54
DFP58 147 39*2 94 30 74 44



Applications of polyester screen printing mesh

  1. It is widely used in PCB, electronics, plastic, metal, paper, textile and other industries and materials,
  2. because of high tension, net distance is small, off-grid and ink stripping outstanding, can get high-precision, high-quality printing The Graphic screen printing CD, DVD printing electronics industry ceramics industry glass printing textiles printing sporting goods printing.
  3. Screen printing net yarn, polyester printing mesh yarn, ceramic printing mesh yarn, glass printing net yarn, circuit board printing net yarn, circuit board printing net yarn, PCB printing net yarn, polyester printing screen


DFP100 Mesh Polyester Screen Printing Mesh With High Accuracy For Electronic 0

DFP100 Mesh Polyester Screen Printing Mesh With High Accuracy For Electronic 1
