Material: | Monofilament Polyester | Color: | White,blue,red |
---|---|---|---|
Keyword: | PET Mesh | Type: | Plain Weave |
Hot Search: | Polyester Mesh Belt | ||
Highlight: | mesh material fabric,plain weave mesh |
PET Mesh Polyester Mesh Belt With Plain Weave , Good Air Permeability
Description of polyester mesh belt:
Advantage of polyester mesh belt:
Polyester mesh belt has the acid and alkali resistance, wear resistance, high temperature resistant, long service life,with smooth surface, the tensile strength, permeability is good,high heat transfer efficiency, for the user to save energy,Install easy to use, interface without stain, strength can reach the normal mesh products.
Application of polyester mesh belt:
Specification of polyester mesh belt:
Weaving Type | Model | Thread Diameter | Density(No.s/cm) | Strength ((N/cm) | Air Permeability (m3/m2h) | ||
(mm) | |||||||
Warp | Weft | Warp | Weft | ||||
2-shed plain weaving | 5802 | 0.75 | 0.8 | 4.7-5 | 4.8-5 | 940 | 20000 |
5102 | 1 | 1 | 4.7-5.2 | 4.3-5 | 1600 | 15000 | |
6702 | 0.7 | 0.7 | 8 | 7 | 1600 | 11000 | |
7102 | 0.7 | 1 | 6.6-7 | 4.3-4.6 | 1100 | 15000 | |
8552 | 0.55 | 0.55 | 7.5-8 | 8.5-9 | 850 | 850-6500 | |
9452 | 0.45 | 0.45 | 10 | 8.6 | 1600 | 16000 | |
9502 | 0.5 | 0.5 | 8.5-9 | 10-10.5 | 750 | 10000 | |
12502 | 0.5 | 0.5 | 13.5 | 8.5 | 1800 | 6500 | |
3shed plain weaving | 8603 | 0.5 | 0.6 | 10 | 9 | 1600 | 14000 |
8903 | 0.9 | 0.9 | 7.8-8 | 5-5.5 | 2100 | 7500-8500 | |
7803 | 0.7 | 0.8 | 8 | 8 | 1600 | 10000 | |
20353 | 0.3 | 0.35 | 22 | 14.5 | 1200 | 13000 |
Shipping of polyester mesh belt:
Service:
1. Samples: free samples with detail specification for you to choose.
2. We will make the exact specifications as customer's requirements
3. Felt and fabric design solution will be provided within 24 hours By Technician Department.
4. There is a Strict quality control process during each production step .Ensuring the quality.
