Product Details:
Payment & Shipping Terms:
|
Color: | White | Name: | NSF Testing Polyester Filtering Mesh 37 Micron Screen Food Grade |
---|---|---|---|
Opening Size: | 28-1270 Micron | Thread Diameter: | 27 Micron -400 Micron |
Certificate: | FDA Certificate,NSF Testing | Application: | Food Grade Filtering Milk,grain,blood And So On |
High Light: | mesh screen fabric,poly mesh fabric |
NSF Testing Polyester Filtering Mesh 37 Micron Screen Food grade
Description:
name | polyester filtering mesh food grade |
mesh couner per inch | 15-460 |
color | white |
hole shape | square |
width | 105cm,115m,127cm,136cm,145cm,157cm,165cm,188cm,220cm,365cm or as your need |
cerficate | FDA, NSF |
length per roll | 30-70m |
Application :
NSF Testing Polyester Filtering Mesh 37 Micron Screen Food grade is widely used in areas as filtration and separation industry.
NSF Testing Polyester Filtering Mesh 37 Micron Screen Food grade Specification:
COUNT (INCH) | COUNT (CM) | DIAMETER (UM) | OPEPING (UM) | OPEN AREA(%) | THICKNESS(UM) | VOLUME (CM³/CM²) |
15 | 6 | 400 | 1270 | 64 | 720 | 460 |
18 | 7 | 350 | 1078 | 64 | 640 | 410 |
20 | 8 | 300 | 950 | 58 | 550 | 319 |
25 | 10 | 250 | 750 | 56 | 620 | 347 |
30 | 12 | 250 | 583 | 49 | 450 | 220 |
30 | 12 | 150 | 683 | 67 | 300 | 201 |
40 | 16 | 200 | 425 | 46 | 400 | 184 |
50 | 20 | 80 | 420 | 71 | 120 | 85 |
50 | 20 | 150 | 350 | 49 | 260 | 127 |
60 | 24 | 100 | 316 | 58 | 136 | 78 |
60 | 24 | 120 | 297 | 50 | 240 | 120 |
73 | 29 | 120 | 225 | 43 | 240 | 103 |
80 | 32 | 64 | 248 | 63 | 95 | 59 |
80 | 32 | 100 | 212 | 46 | 200 | 92 |
85 | 34 | 100 | 195 | 44 | 221 | 97 |
90 | 36 | 100 | 178 | 41 | 216 | 88 |
100 | 39 | 55 | 200 | 61 | 88 | 53 |
100 | 39 | 80 | 176 | 47 | 150 | 70 |
110 | 43 | 80 | 153 | 43 | 130 | 56 |
120 | 47 | 55 | 158 | 55 | 88 | 48 |
120 | 47 | 71 | 142 | 44 | 135 | 59 |
135 | 53 | 55 | 133 | 50 | 86 | 43 |
135 | 53 | 64 | 125 | 44 | 100 | 44 |
150 | 59 | 64 | 105 | 38 | 100 | 38 |
160 | 64 | 55 | 101 | 42 | 98 | 41 |
160 | 64 | 64 | 92 | 35 | 120 | 42 |
180 | 72 | 48 | 91 | 43 | 78 | 66 |
180 | 72 | 55 | 84 | 37 | 100 | 37 |
200 | 80 | 48 | 77 | 38 | 74 | 28 |
195 | 77 | 55 | 75 | 33 | 105 | 34 |
230 | 90 | 48 | 63 | 33 | 85 | 28 |
250 | 100 | 40 | 60 | 36 | 70 | 25 |
280 | 110 | 40 | 51 | 31 | 85 | 26 |
305 | 120 | 40 | 43 | 27 | 68 | 18 |
355 | 140 | 34 | 37 | 27 | 58 | 15 |
380 | 150 | 31 | 36 | 29 | 46 | 13 |
420 | 165 | 31 | 30 | 24 | 46 | 11 |
460 | 180 | 27 | 28 | 26 | 56 | 14 |
NSF Testing Polyester Filtering Mesh 37 Micron Screen Food gradeFeatures:
NSF Testing Polyester Filtering Mesh 37 Micron Screen Food gradeShipping:
Processing of polyester filter mesh screen:
yarn→Raw yarn inspection→Warping arranging→Drawing in heddle→Drawing in reed→weaving→Initial survey→washing→Heat setting treatment→Physical properties inspection→Products inspection→product
Our factory introduction:
Anping County PFM Screen Co.,Ltd is located in the famous "home town of wire mesh" -Anping county industrial park, covers an area of 40000 square meters, construction area of 11000 square meters, It has 10000 grade clean production workshop 1500 square meters, employees 163 people, engineering technical personnel 56 people.Introduced the world's most advanced polyester screen mesh production line including Switzerland 330 cm p7100 gripper loom, German intelligent electronic sectional warping machines, automatic heat setting machine, washing machine and other equipment of 46.Has the most advanced test equipments.
