Product Name: | Micron Filter Wire Mesh Sieve | Application: | Filtering,screening,sieving |
---|---|---|---|
Size: | Usually 1.02meter*30meter Per Roll | Hot Search: | Micron Mesh Sieve |
Feature: | Corrosion Resistant | Width: | 40” And 48” |
Highlight: | stainless steel mesh screen,crimped wire mesh |
120 / 150 / 180 / 200 / 400 / 500 micron Stainless Steel Micron Filter Wire Mesh Sieve / Screen
Decription :
PFM Screen Co.,Ltd can produce micron sieve mesh, wire screen ,filter mesh and micron sieve .
The mesh count per inch can be from 60 to 635 mesh, this kind of wire mesh is ultra thin,so we all call is wire mesh cloth,woven mesh fabric,metal wire cloth.
Micron mesh has very precise opening size base on standard mesh count per inch,uniform wire diameter.So stainless steel filter wire mesh is widely used in pharma,chemical analysis,airspace,air liquid and small solid filtering and seperation.
Features of stainless steel woven filter wire mesh
1. corrosion resistant,stainless steel grade is acid and alkali resistant.
2. high temperature resistant,can bear 800 degree centigrade
3. uniform wire diameter,error is +-2micron
4. stable structure
Specifications of steel wire mesh:
1. Consistent pore size distribution guarantees a significantly higher particle separation
2. material:SUS304 316 316L,316L is mainly designed for marine aquaculture and pharmacy.
3. mesh count per liner inch:2-635mesh
4. wire thread can be from 0.08” to 0.0008”
5.width:usually 40” and 48”,special can be ordered
mesh count per inch | wire diameter/ mm | opening size/mm | material |
60meshx60mesh | 0.15 | 0.27 | 304 or316 |
70meshx70mesh | 0.12 | 0.24 | 304 or316 |
80meshx80mesh | 0.13 | 0.19 | 304 or316 |
90meshx90mesh | 0.12 | 0.16 | 304 or316 |
100meshx100mesh | 0.10 | 0.15 | 304 or316 |
120meshx120mesh | 0.09 | 0.12 | 304 or316 |
150meshx150mesh | 0.063 | 0.11 | 304 or316 |
180meshx180mesh | 0.053 | 0.09 | 304 or316 |
200meshx200mesh | 0.053 | 0.07 | 304 or316 |
250meshx250mesh | 0.040 | 0.063 | 316 |
300meshx300mesh | 0.040 | 0.044 | 316 |
325meshx325mesh | 0.035 | 0.043 | 316L |
350meshx350mesh | 0.030 | 0.042 | 316L |
400meshx400mesh | 0.030 | 0.033 | 316L |
450meshx450mesh | 0.028 | 0.028 | 316L |
500meshx500mesh | 0.025 | 0.026 | 316L |
Applications of 120 / 150 / 180 / 200 / 400 / 500 micron Stainless Steel Micron Filter Wire Mesh Sieve / Screen:
