100% Polyester Mesh Screen Fabric With High Dimensional Accuracy , Low Elongation

Name: 100% Polyester Mesh Screen Fabric With High Dimensional Accuracy , Low Elongation
Brand: Anping County Comesh Filter Co.,Ltd
SKU: PFM-Lyd
Price: 129.10 USD
Availability: InStock

Product Details

Place of Origin: Hebei China

Brand Name: PFM

Certification: FDA

Model Number: PFM-Lyd

Payment & Shipping Terms

Minimum Order Quantity: 1 sqm

Price: Negotiable

Packaging Details: Plastic bag inside on one roll and carton case outside,or cut into small pieces and plastic bag.

Delivery Time: 3-10days

Payment Terms: L/C, D/A, T/T, Western Union, ，Trade assurance,Paypal

Supply Ability: 3000meters per week

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                    screen mesh fabric, polyester mesh fabric


Material:	100%Polyester	Mesh:	15-460mesh/inch
Length:	30-70m/roll Or Cut Into Pieces.	Width:	1.15-3.6m
Delivery:	5-10days	Color:	Yellow,white,black
Weave:	Plain Weave Or Twill Weave	Aperture:	23-600micron

Material:	100%Polyester
Mesh:	15-460mesh/inch
Length:	30-70m/roll Or Cut Into Pieces.
Width:	1.15-3.6m
Delivery:	5-10days
Color:	Yellow,white,black
Weave:	Plain Weave Or Twill Weave
Aperture:	23-600micron

Product Description

Low Elongation 100%Polyester Printing Mesh With High Dimensional Accuracy

1. Description

Material :manufactured by 100% nylon monofilament yarns
Opening :the mesh with great precision exact and regular square holes
Chemicals :no unwanted chemicals,no any chemicals treatment in the production process
Safe Grade :very safe,very thin,food grade
Shape :can made by disc,tube,piece,roll any sizes and shape,max roll length1000m
Temperature :high tensile,use temperature under 200℃
Dimensoinal :very good dimensional stability

2. Application

We mainly offer high quality and high precision polyester and polyamide bolting screen ranging from 60-420 mesh. This product is widely used in printing and plate-making in electronic, textile, ceramics industry, also used for melting filtration in space flight, petroleum chemical and other high-tech fields. This product is the most advanced high-tech products for silk printing.

3.Specification

COUNT (INCH)	COUNT (CM)	DIAMETER (UM)	OPEPING (UM)	OPEN AREA(%)	THICKNESS(UM)	VOLUME (CM³/CM²)	MAX TEN SION(N/CM)
15	6	400	1270	64	720	460	30-60
18	7	350	1078	64	640	410	30-60
20	8	300	950	58	550	319	30-60
25	10	250	750	56	620	347	30-60
30	12	250	583	49	450	220	30-60
30	12	150	683	67	300	201	30-60
40	16	200	425	46	400	184	30-60
50	20	80	420	71	120	85	35-37
50	20	150	350	49	260	127	30-60
60	24	100	316	58	136	78	35-40
60	24	120	297	50	240	120	35-60
73	29	120	225	43	240	103	35-60
80	32	64	248	63	95	59	30-34
80	32	100	212	46	200	92	35-40
85	34	100	195	44	221	97	35-40
90	36	100	178	41	216	88	35-40
100	39	55	200	61	88	53	25-30
100	39	80	176	47	150	70	35-37
110	43	80	153	43	130	56	35-37
120	47	55	158	55	88	48	25-30
120	47	71	142	44	135	59	30-34
135	53	55	133	50	86	43	25-30
135	53	64	125	44	100	44	26-31
150	59	64	105	38	100	38	26-31
160	64	55	101	42	98	41	25-30
160	64	64	92	35	120	42	30-34
180	72	48	91	43	78	66	27-29
180	72	55	84	37	100	37	25-30
200	80	48	77	38	74	28	27-29
195	77	55	75	33	105	34	25-30
230	90	48	63	33	85	28	27-29
250	100	40	60	36	70	25	20-24
280	110	40	51	31	85	26	20-24
305	120	40	43	27	68	18	20-24
355	140	34	37	27	58	15	22-24
380	150	31	36	29	46	13	21-23
420	165	31	30	24	46	11	21-23
460	180	27	28	26	56	14	20-22

4.Feature advantage

Polyester is particularly recommended for use in manufacturing conditions in excess of 100°C. It is suitable up to a maximum working temperature of 150°C in the chemical pH range 1-7.

1.High tension and smooth surface

2.Good diathermancy

3.High air permeability

4.Acid resistance and Alkali resistance

5.Long working life

6. Hard wear and easy cleaning

7.We can do as customer's requests and sample.
