Spiral Diamond Weave Aluminum Spray Painting Decorative Wire Mesh Ceiling Divider Panel Black

Matte Black Spiral Mesh Feature Panel

The matte black reading of a spiral diamond weave. Because the coating is nearly flat, the pattern is carried by shadow rather than by reflection: the spiral intersections hold a soft shade line while the open diamonds disappear into the background. Used overhead, this makes a ceiling divider read as a graphic layer instead of a solid plane.

Why matte black changes the perception of the panel

On a high gloss finish the wire highlights catch the light and the mesh looks denser than it is. At 5 to 8 gloss units the wire faces stay dark and only the silhouette registers, so a 58 percent open panel appears lighter and the ceiling behind it stays visible. This is the finish most often chosen for interiors where the mesh must not compete with the lighting design.

Spiral double crimp over a large panel

The double wire spiral at 20 mm pitch is what allows a 1220 x 2440 mm panel to hang without an intermediate support. The two wires at each intersection share the load, which keeps the diamond aperture uniform from the centre of the panel to the edge. Aperture is held within 1 mm across the full sheet.

Slim frame for overhead mounting

The 20 x 20 mm frame is deliberately minimal so that the panel reads as mesh rather than as a framed object. Fixing is by concealed cleats on the top rail plus adjustable hangers, which allows levelling across a 2400 mm span. For railing use the frame can be reinforced at the base rail without changing the visible section.

Coating care on dark colours

Matte black shows handling marks more than light colours. Panels are packed with a peel-off film and we recommend leaving it in place until the panel is hung. Minor scuffs on matte coating cannot be polished out, so a small touch-up aerosol from the same batch is included in each crate.

Specification Summary

Typical Applications

• Ceiling divider and suspended art panel
• Interior railing infill in stairwells
• Retail and hospitality feature screen
• Lobby and showroom backdrop

Order Notes

Matte black is held in stock in this aperture; other RAL colours run 25 days. For ceilings with sprinkler or lighting penetrations, provide the penetration layout and panels will be cut before coating.
