Heatresistant Carbon Stainless Steel Mesh Conveyor Belt For Cooling Elevator

Heatresistant Carbon Stainless Steel Mesh Conveyor Belt For Cooling Elevator
Heatresistant Carbon Stainless Steel Mesh Conveyor Belt For Cooling Elevator Heatresistant Carbon Stainless Steel Mesh Conveyor Belt For Cooling Elevator Heatresistant Carbon Stainless Steel Mesh Conveyor Belt For Cooling Elevator

Large Image :  Heatresistant Carbon Stainless Steel Mesh Conveyor Belt For Cooling Elevator

Product Details:
Place of Origin: China
Brand Name: COMESH
Certification: FDA
Model Number: CO-HE070722
Payment & Shipping Terms:
Minimum Order Quantity: 5 meter
Price: negotiable
Packaging Details: plywood case or pallet
Delivery Time: 15 days
Payment Terms: T/T, L/C
Supply Ability: 500 meter per month
Detailed Product Description
Application: Manufacturing Plant, Food And Beverage Factory, Construction Material: Stainless Steel 304 316,carbon Steel,galvanized Steel
Features: Heat Resistant, Heavy Loading Weight Size: Can Be Customized As Per Your Requirement
High Light:

heatresistant stainless steel mesh conveyor belt

,

gi stainless steel mesh conveyor belt

,

cooling elevator wire mesh conveyor belt

Stainless Carbon Steel Wire Mesh Chain Metal Flat Plate Link Slat Perforated Conveyor Belt for cooling elevator





Features of metal slat conveyor belt:





Plate Link Conveyor Belt is strong, driven by chain, made of metal plate, and very suited to heavy load applications, running smoothly in the conveying process, easy to install and replace, and long in service life.



Its self-supporting structure makes it be used over large widths without any support. extremely robust design and high load capacity, making it the perfect choice for arduous engineering processes such as presswork, die-casting and forging.



Plate belts have side plates and cross flights in various combinations of height and thickness to suit different customers' requirements. They can satisfy light to heavy load capacity. Chain edge plate belts are also available in side plates and cross flights. The chains can be fixed with cotter pins or washers, which are convenient to disassemble and maintain.



Metal plate conveyor belt consists of hinged slats with or without perforations. Perforated plate belt is ideal for drainage conveyor system. The size of perforation range can be customized, its possibility to have of al kinds of perforations to fit the product production line.



Specifications of Plate Link Conveyor Belt

Specifications
Item

Chain Pitch

(mm)

Rod Diameter

(mm)

Plate Thickness

(mm)

PLCB-01 25.4 5 1
PLCB-02 25.4 6 1
PLCB-03 25.4 6 1.5
PLCB-04 31.75 6 1
PLCB-05 31.75 6 1.5
PLCB-06 31.75 8 2
PLCB-07 38.1 6 1
PLCB-08 38.1 6 1.5
PLCB-09 38.1 8 1
PLCB-10 38.1 8 1.5
PLCB-11 38.1 8 2
PLCB-12 50.8 6 1.2
PLCB-13 50.8 8 1
PLCB-14 50.8 8 1.5
PLCB-15 50.8 10 2
PLCB-16 50.8 10 3
PLCB-17 63.5 10 2
PLCB-18 63.5 10 1.5
PLCB-19 63.5 10 3
PLCB-20 80 8 1.5
PLCB-21 80 8 2
PLCB-22 80 10 2
PLCB-23 80 10 2.5
PLCB-24 100 10 1.5
PLCB-25 100 10 2
PLCB-26 100 14 2
PLCB-27 100 14 3
PLCB-28 101.6 10 4
PLCB-29 106.6 14 4
PLCB-30 125 20 3
NOTE: Custom specification is available if you can't find the suitable size.





Applications of belt chip conveyor chain:

  • Cooling systems
  • Washing systems
  • Waste treatment systems
  • Blanching systems
  • Sievingsystems
  • Drying systems
  • Sorting systems
  • Sorting systems
  • Elevating systems
  • De-Elevating systems
  • Bread production systems
  • Product handling systems
  • Transport systems
  • Drainage systems
