Blue Square Hole Polyester Mesh Belt , Food Industries Drying , Washing And Conveyor

Brand Name:	PFM
Model Number:	PFM-Hel
MOQ:	1 Square Meter
Price:	Negotiable
Payment Terms:	L/C, T/T, Western Union, ,Paypal,Trade Assurance
Supply Ability:	2000 Square Meters Per Quarter

Detail Information

Product Description

Detail Information

Place of Origin:

Hebei,China

Certification:

FDA

Material:

100% Polyester Monofilament Yarn

Weave Type:

Plain Weave

Color:

Blue

Name:

Plain Weave Polyester Mesh Belt Under 180 Degree With High Temperature

Delivery:

Within 7 Days

Type:

2-shed

Packaging Details:

Plastic Bag Inaide And Plywood Case Outside Or According To Your Needs.

Highlight:

mesh material fabric

plain weave mesh

Product Description

Blue Square hole Polyester Mesh Belt ,food industries drying,washing and conveyor

Description and applications:

Blue Square hole Polyester Mesh Belt ,food industries drying,washing and conveyor is widely used in special lines,such as mining sieving,mineralseparation,goldbenefication,paper pulps making,sulplate pulp packing and cardboard pulp,fiberboard plants as well as tailings disposal,colliery,food and medicine as filter belt.

This kind of Polyester Mesh Belt has features of high temperature resistant,long life span.food grade material,easy to clean

Blue Square hole Polyester Mesh Belt ,food industries drying,washing and conveyor Specification:

Weaving Type	Model	Thread Diameter		Density(No.s/cm)		Strength ((N/cm)	Air Permeability (m3/m2h)
		(mm)		Density(No.s/cm)
		Warp	Weft	Warp	Weft
2-shed plain weaving	05802	0.75	0.8	4.7-5	4.8-5	940	20000
	05102	1	1	4.7-5.2	4.3-5	1600	15000
	06702	0.7	0.7	8	7	1600	11000
	07102	0.7	1	6.6-7	4.3-4.6	1100	15000
	08552	0.55	0.55	7.5-8	8.5-9	850	850-6500
	09452	0.45	0.45	10	8.6	1600	16000
	09502	0.5	0.5	8.5-9	10-10.5	750	10000
	12502	0.5	0.5	13.5	8.5	1800	6500
3shed plain weaving	8603	0.5	0.6	10	9	1600	14000
	8903	0.9	0.9	7.8-8	5-5.5	2100	7500-8500
	7803	0.7	0.8	8	8	1600	10000
	20353	0.3	0.35	22	14.5	1200	13000

Plain Weave Polyester Mesh Belt With High Temperature Under 180 Degree aperture:

400micron,500micron,600micron,700micron,800micron,1000micron,1500micron,1800micron,2000micron,

2500micron,3000micron,4000micron.

Size of polyester plain weave mesh belt

Standard widths in stock:1.0m-6.0m;length is available as the request

Edge of polyester plain weave mesh belt

	edges sealed by glue
	edges sealed by mesh
	edges sealed by heat resistant fabric

Shipping of polyester plain weave mesh belt

For small quantity, shipped by courier.
For large quantity, shiped by air or by sea.
Tracking number will be emailed to you after order has been shipped.
If you have forwarder in China, we can send to your forwarder for free.
