Polyester Screen Printing Mesh 280 Mesh/Inch 34micron Thread

Polyester Screen Printing Mesh 280 Mesh/Inch 34micron Thread

Polyester Screen Printing Mesh 280 Mesh/Inch 34micron Thread

Brand Name: Comehs-
Model Number: Comesh-Ang
MOQ: 30meter
Price: Negotiable
Payment Terms: D/A, L/C, D/P, T/T, Western Union, ，Trade assurance,Paypal
Supply Ability: 3000meters per week
Detail Information
Product Description
Detail Information
Place of Origin:
Hbei,China
Certification:
FDA
Thread Diameter:
34micron
Mesh/inch:
280mesh/inch
Weave:
1:1
Sample:
Offered
Aperture:
48micron
Thickness:
58micron
Name:
Professional 150 200 300 350 420 500 Micron Polyester Screen Printing Mesh
Color:
White，black，yellow，red，blue
Width:
1-3.2m
Packaging Details:
plastic bag inside, carton case outside,5-10rolls in one carton
Highlight:

screen printing fabric mesh

,

screen printing mesh roll

Product Description
Professional Polyester Screen Printing Mesh
Product Specifications
Attribute Value
Thread diameter 34micron
Mesh/inch 280mesh/inch
Weave 1:1
Sample offered
Aperture 48micron
Thickness 58micron
Color options white, black, yellow, red, blue
Width 1-3.2m
Key Features
  • High tension and low elongation
  • Minimal tension loss after high strength use
  • Precise standard size and filtration values
  • (±)2-6micron thickness tolerance
  • Enables faster printing speed with finer printing effects
Applications

Widely used in textile printing, T-shirt printing, ceramic printing, glass printing, and PCB printing industries.

Technical Specifications
COUNT (INCH) COUNT (CM) DIAMETER (UM) OPENING (UM) OPEN AREA(%) THICKNESS(UM) VOLUME (CM³/CM²) MAX TENSION(N/CM)
15 6 400 1270 64 720 460 30-60
460 180 27 28 26 56 14 20-22
Recommended Mesh Sizes
  • 20-40 mesh: Ideal for glitter inks requiring open mesh
  • 60 mesh: Best for smaller glitter and shimmer inks
  • 80 mesh: Excellent for thick ink layers and foil adhesive
  • 110 mesh: Perfect for white and thick inks with good coverage
  • 120 mesh: Most common size for white and thick colored inks
  • 155 mesh: General purpose textile printing with basic detail
  • 200-305 mesh: High-end fine detail printing and halftones
Production Process
Polyester Screen Printing Mesh 280 Mesh/Inch 34micron Thread 0
Packaging
  • Mesh rolls in PP bags
  • 2-12 rolls per carton
  • Waterproof outer bags
  • Reinforced with package belts
Minimum Order & Samples

Standard MOQ is 30 meters (flexible for smaller quantities - please inquire).

Free samples available (up to 2 meters) with buyer responsible for freight.

Customer Service
Pre-Sale Services
  • Inquiry and consulting support
  • Sample testing
  • Factory tours available
After-Sale Services
  • Prompt shipment tracking
  • Usage training
  • Replacement for unsatisfactory products
Polyester Screen Printing Mesh 280 Mesh/Inch 34micron Thread 1 Polyester Screen Printing Mesh 280 Mesh/Inch 34micron Thread 2 Polyester Screen Printing Mesh 280 Mesh/Inch 34micron Thread 3
