90T Polyester Screen Printing Mesh 48 Micron for Glass Printing

Brand Name:	PFM
Model Number:	PFM-Hel
MOQ:	30meter
Price:	Negotiable
Payment Terms:	D/A, L/C, D/P, T/T, Western Union, ，Trade assurance,Paypal
Supply Ability:	3000meters per week

Detail Information

Product Description

Detail Information

Place of Origin:

Hbei,China

Certification:

FDA

Product Name:

100% Monofilament 53 Inch 90T Polyester Screen Printing Mesh For Glass Printing

Thread Diameter:

48 Micron

Mesh/inch:

135

Width:

53 Inch

Application:

Screen Printing For Glass

Feature:

No Surface Treatment

Packaging Details:

plastic bag inside, carton case outside,5-10rolls in one carton

Highlight:

screen printing fabric mesh

screen printing mesh roll

Product Description

Custom 63 Micron Polyester Screen Printing Mesh 90T With 100% Monofilament

Product Specifications

Attribute	Value
Product Name	100% Monofilament 53 Inch 90T Polyester Screen Printing Mesh For Glass Printing
Thread Diameter	48 micron
Mesh/inch	135
Width	53 inch
Application	Screen printing for glass
Feature	No surface treatment

Product Description

100% Monofilament 53 Inch 90T Polyester Screen Printing Mesh is specifically designed for high-quality glass printing applications.

Applications

This polyester screen printing mesh is widely used in:

Textile printing
T-shirt printing
Ceramic printing
Glass printing
PCB printing industry

Detailed Specifications

Mesh count per cm	90
Thread diameter	48
Color	White / Yellow
Opening size	63 micron
Width	115cm, 127cm, 136cm, 145cm, 157cm, 165cm, 188cm, 220cm (Max width: 3.65cm)

Key Features

High tension threshold and breaking point
High modulus, low elongation monofilament polyester yarn
Resistant to chemicals, abrasion, heat and moisture
Minimal tension loss during stretching process
Improved registration due to stable fabric tension
Excellent antistatic properties
No surface treatment required

Technical Specifications

COUNT (INCH)	COUNT (CM)	DIAMETER (UM)	OPENING (UM)	OPEN AREA(%)	THICKNESS(UM)	VOLUME (CM³/CM²)	MAX TENSION(N/CM)
15	6	400	1270	64	720	460	30-60
230	90	48	63	33	85	28	27-29

Production Process

Factory Information

Anping County PFM Screen Co., Ltd is located in the famous "home town of wire mesh" - Anping county industrial park. Our facility covers 40,000 square meters with a 10,000 grade clean production workshop of 1,500 square meters. We employ 163 people including 56 engineering technical personnel.

Our production line includes:
