74" 48T 70 Micron Polyester Screen Printing Mesh for Ceramics

Brand Name:	PFM
Model Number:	PFM-Hel
MOQ:	30meter
Price:	Negotiable
Payment Terms:	D/A, L/C, D/P, T/T, Western Union, ，Trade assurance,Paypal
Supply Ability:	3000meters per week

Detail Information

Product Description

Detail Information

Place of Origin:

Hbei,China

Certification:

FDA

Product Name:

Low Elasticity 74" 48T - 70 Micron Polyester Screen Printing Mesh For Ceramics Printing

Thread Diameter:

70micron

Mesh/inch:

122

Application:

Ceramic Screen Printing Mesh

Width:

74"

Feature:

No Surface Treatment

Packaging Details:

plastic bag inside, carton case outside,5-10rolls in one carton

Highlight:

screen printing fabric mesh

monofilament polyester mesh

Product Description

Low Elasticity Polyester Screen Printing Mesh 70 Micron For Ceramics/T-Shirt

Product Specifications

Product Name	Low Elasticity 74" 48T - 70 Micron Polyester Screen Printing Mesh For Ceramics Printing
Thread Diameter	70 micron
Mesh per Inch	122
Application	Ceramic screen printing mesh
Width	74"
Feature	No surface treatment

Key Features

High tension threshold and breaking point
High modulus, low elongation monofilament polyester yarn
Resistant to chemicals, abrasion, heat and moisture
Minimal tension loss during stretching process
Improved registration due to stable fabric tension
Good antistatic properties
No surface treatment required

Applications

Polyester Screen Printing Mesh is widely used in textile printing, T-shirt printing, ceramic printing, glass printing and PCB printing industries.

Detailed Specifications

Mesh Count per cm	Thread Diameter (micron)	Color	Opening Size (micron)	Available Widths
48	70	White	138	115cm, 127cm, 136cm, 145cm, 157cm, 165cm, 188cm, 220cm (Max width: 3.65m)

Technical Specifications

Count (inch)	Count (cm)	Diameter (µm)	Opening (µm)	Open Area (%)	Thickness (µm)	Volume (cm³/cm²)	Max Tension (N/cm)
15	6	400	1270	64	720	460	30-60
120	48	70	138	44	135	59	30-34

Recommended Mesh Sizes

20-40 mesh: Ideal for glitter inks requiring very open mesh
60 mesh: Best for smaller glitter and most shimmer inks
80 mesh: Excellent for high-density printing and foil adhesive
110 mesh: Perfect for spot color printing with thick inks
120 mesh: Most common size for white and thick viscosity inks
155 mesh: General purpose textile printing with basic detail
200-305 mesh: High-end fine detail printing and halftones

Packaging

Mesh rolls in PP bags
2-12 rolls per carton
Waterproof outer bags
Reinforced with package belts

Ordering Information

Minimum Order Quantity: Typically 30 meters (contact for smaller quantities)

Samples: Free samples available (max 2 meters), buyer pays shipping

Customer Service

Pre-Sale Support:

Inquiry and consulting
Sample testing
Factory visits

After-Sale Support:

Prompt shipment tracking
Usage training
Replacement for dissatisfaction
