34um Polyester Screen Printing Mesh 120T for Glass Printing

34um Polyester Screen Printing Mesh 120T for Glass Printing

34um Polyester Screen Printing Mesh 120T for Glass Printing

Brand Name:	PFM
Model Number:	PFM-Hel
MOQ:	30meter
Price:	Negotiable
Payment Terms:	D/A, L/C, D/P, T/T, Western Union, ，Trade assurance,Paypal
Supply Ability:	3000meters per week

Detail Information

Product Description

Detail Information

Place of Origin:

Hbei,China

Certification:

FDA

Product Name:

100% Monofilament White 120T - 34 Polyester Screen Printing Mesh For Glass Printing

Thread Diameter:

34um

Mesh/inch:

305

Application:

Glass Screen Printing

Packaging Details:

plastic bag inside, carton case outside,5-10rolls in one carton

Highlight:

screen printing mesh roll

,

monofilament polyester mesh

Product Description

100% Monofilament White 120T - 34 Polyester Screen Printing Mesh For Glass Printing

Product Specifications

Attribute	Value
Product Name	100% Monofilament White 120T - 34 Polyester Screen Printing Mesh For Glass Printing
Thread Diameter	34μm
Mesh per Inch	305
Primary Application	Glass Screen Printing

Key Features

High tension threshold and breaking point
High modulus, low elongation monofilament polyester yarn
Resistant to chemicals, abrasion, heat and moisture
Minimal tension loss during stretching process
Improved registration due to stable fabric tension
Good antistatic properties with no surface treatment required

Detailed Specifications

Mesh Count per cm	120
Thread Diameter	34μm
Color	White / Yellow
Opening Size	49 micron
Available Widths	115cm, 127cm, 136cm, 145cm, 157cm, 165cm, 188cm, 220cm (Max width: 3.65m)

Applications

Polyester Screen Printing Mesh is widely used in:

Textile printing
T-shirt printing
Ceramic printing
Glass printing
PCB printing industry

Complete Mesh Specifications

COUNT (INCH)	COUNT (CM)	DIAMETER (UM)	OPENING (UM)	OPEN AREA(%)	THICKNESS(UM)	VOLUME (CM³/CM²)	MAX TENSION(N/CM)
15	6	400	1270	64	720	460	30-60
305	120	34	49	30	55	16	22-24

Recommended Mesh Selection Guide

20-40 mesh: Ideal for glitter inks requiring very open mesh
60 mesh: Best for smaller glitter and most shimmer inks
80 mesh: Perfect for thick ink layers and foil adhesive
110 mesh: Excellent for white and thick inks with good coverage
120 mesh: Most popular size for white and thicker colored inks
155 mesh: General purpose textile printing with basic detail
200 mesh: Detailed prints requiring thinner ink layers
230-305 mesh: High-end fine detail and halftone printing

Production Process

34um Polyester Screen Printing Mesh 120T for Glass Printing 0

Packaging Details

Mesh rolls packed in PP bags
2-12 rolls per carton
Waterproof outer bags
Reinforced with package belts

Our Services

Pre-Sale Services

Inquiry and consulting support
Sample testing
Factory tours

After-Sale Services

Prompt shipment tracking
Usage training
Replacement for dissatisfaction

34um Polyester Screen Printing Mesh 120T for Glass Printing 1
