120T-31 Polyester Screen Printing Mesh for Ceramics

Brand Name:	PFM
Model Number:	PFM-Hel
MOQ:	30meter
Price:	Negotiable
Payment Terms:	D/A, L/C, D/P, T/T, Western Union, ，Trade assurance,Paypal
Supply Ability:	3000meters per week

Detail Information

Product Description

Detail Information

Place of Origin:

Hbei,China

Certification:

FDA

Product Name:

White 132 Inch 120T - 31 Polyester Screen Printing Mesh For Ceramics Printing

Thread Diameter:

31 Micron

Mesh/inch:

300

Application:

Ceramic Screen Printing Mesh

Packaging Details:

plastic bag inside, carton case outside,5-10rolls in one carton

Highlight:

screen printing mesh roll

monofilament polyester mesh

Product Description

31 Thread 100% Monofilament Polyester Mesh 120T - 31 With No Surface Treatment

Product Specifications

Product Name	White 132 Inch 120T - 31 Polyester Screen Printing Mesh For Ceramics Printing
Thread Diameter	31 micron
Mesh/inch	300
Application	Ceramic screen printing mesh

Product Overview

White 132 Inch 120T - 31 Polyester Screen Printing Mesh is specially designed for ceramics printing applications, offering superior performance in textile, T-shirt, glass, and PCB printing industries.

Detailed Specifications

Mesh Count per cm	120
Thread Diameter	31 micron
Color	White / Yellow
Opening Size	52 micron
Available Widths	115cm, 127cm, 136cm, 145cm, 157cm, 165cm, 188cm, 220cm (Max width: 3.65m)

Key Features

High tension threshold and breaking point
High modulus, low elongation monofilament polyester yarn
Resistant to chemicals, abrasion, heat and moisture
Minimal tension loss during stretching process
Improved registration due to stable fabric tension
Excellent antistatic properties
No surface treatment required

Technical Specifications

COUNT (INCH)	COUNT (CM)	DIAMETER (UM)	OPENING (UM)	OPEN AREA(%)	THICKNESS(UM)	VOLUME (CM³/CM²)	MAX TENSION(N/CM)
305	120	31	52	35	49	17	21-23

Recommended Applications by Mesh Size

20-40 mesh: Ideal for glitter inks requiring very open mesh
60 mesh: Perfect for smaller glitter and most shimmer inks
80 mesh: Excellent for shimmer inks, thick ink layers, and foil adhesive
110 mesh: Optimal for white and thick inks, great for spot color printing
120 mesh: Most common size for white ink and thicker viscosity colored inks
155 mesh: General purpose textile printing with basic to semi-fine detail
200 mesh: Detailed prints requiring thinner ink layers
230-280 mesh: High-end fine detail printing and halftones
305 mesh: Extremely high detail with thin ink layers, ideal for halftones and process prints
