316 Stainless Steel Wire Mesh With Dutch Weave Mesh Used For Oil Filtration

Certification
China Anping County Comesh Filter Co.,Ltd certification
China Anping County Comesh Filter Co.,Ltd certification
Customer Reviews
Never appear quality problem, timely delivery, very satisfied.

—— Eric

Money and treasures will be plentiful

—— Yee

Integrity enterprises, quality assurance, timely delivery, first-class after-sale.

—— Mario

I'm Online Chat Now

316 Stainless Steel Wire Mesh With Dutch Weave Mesh Used For Oil Filtration

316 Stainless Steel Wire Mesh With Dutch Weave Mesh Used For Oil Filtration
316 Stainless Steel Wire Mesh With Dutch Weave Mesh Used For Oil Filtration 316 Stainless Steel Wire Mesh With Dutch Weave Mesh Used For Oil Filtration 316 Stainless Steel Wire Mesh With Dutch Weave Mesh Used For Oil Filtration

Large Image :  316 Stainless Steel Wire Mesh With Dutch Weave Mesh Used For Oil Filtration

Product Details:

Place of Origin: Hebei,China
Brand Name: Comesh
Certification: SGS
Model Number: Comesh-ANG

Payment & Shipping Terms:

Minimum Order Quantity: 1 square meter
Price: Negotiable
Packaging Details: waterproof paper inside,plywood case outside or according to your needs.
Delivery Time: in 5 days for goods in stock
Payment Terms: L/C, T/T, Western Union, MoneyGram,Paypal,Trade assurance
Supply Ability: 2000 square meter per month
Detailed Product Description
Product Name: Dutch Wire Mesh Application: Oil Filtration
Hot Search: Stainless Steel Wire Mesh Weave Type: Dutch Weave
Length: 30-70m/roll Width: 1m,1.22m
High Light:

stainless steel mesh screen

,

crimped wire mesh

                  316 Stainless Steel Wire Mesh With Dutch Weave Mesh Used For Oil Filtration


Description of stainless steel wire mesh:

Stainless steel seats are made of high quality stainless steel wire woven. The main features are the warp, weft wire diameter and density have a greater contrast, and thus the net thickness and filter accuracy and service life than the hole network has improved significantly, and its filter accuracy is square hole mesh can not be achieved.

material SUS304 316 316L,304L
weave typedutch plain or dutch twill weave
Styleplain weave dutch mesh and twill weave dutch mesh
wire diameterMin diameter is 0.015mm
aperture size 3-347micron
Mesh/inchaccording to your request


Dutch weave wire mesh is another kind of stainless steel woven wire mesh,this mesh count of warp and weft is different,the thickness is bigger than than of stainless steel fine mesh,Dutch weave wire mesh is widely used as micron filtering material of environmental protection equipment.

Reverse dutch weave wire mesh is a kind of dutch weave wire mesh,the mesh count per inch of warp wire is more than that of weft wire,then to form much more thickner of mesh surface.reverse dutch weave wire mesh is widely used as plastic extruder machine.

Applications of stainless steel wire mesh:
Mainly for gas, liquid filtration and other media separation; widely used in precision pressure filters, fuel filtration,Vacuum filter, do filter raw materials, aerospace, oil refining, medicine, sugar, oil, chemicals, chemical fiber, rubber, tire manufacturing,Metallurgy, food, health research and other industries

Specifications of dutch wire mesh

Mesh/count

Warp wire

( inch)

Weft wire

(inch)

Absolute rating

 (um)

Nominal rating

(um)

Weight (per 100sq)
8*200.0140.0126330-35028049
12*640.0240.0165270-29020084
14*880.020.013220-24015075
16*800.01960.0134225-23514079
24*1100.0150.01115-1258055
24*1280.020.004110-1207534
30*1500.0090.007110-1126333
30*1502*.009.00795-1136033
40*2000.0070.005570-755527
50*2500.00550.004558-634022
80*4000.0050.00340-453517
30*2500.010.008110-1205366
80*7000.0040.00335-402525
120*4000.0040.002550-554015
165*8000.00280.00225-281514
200*6000.00240.0018302010
165*14000.00280.001616-201014
200*14000.00280.001612-14515
325*23000.00140.0018-9210
10400*28000.0010.00086-718

8
316 Stainless Steel Wire Mesh With Dutch Weave Mesh Used For Oil Filtration 0
