Plain Weave 165T Polyester Screen Printing Mesh For Screen Printing

Plain Weave 165T Polyester Screen Printing Mesh For Screen Printing
Plain Weave 165T Polyester Screen Printing Mesh For Screen Printing Plain Weave 165T Polyester Screen Printing Mesh For Screen Printing Plain Weave 165T Polyester Screen Printing Mesh For Screen Printing Plain Weave 165T Polyester Screen Printing Mesh For Screen Printing

Large Image :  Plain Weave 165T Polyester Screen Printing Mesh For Screen Printing

Product Details:
Place of Origin: Hbei,China
Brand Name: PFM
Certification: FDA
Model Number: PFM-Lyd
Payment & Shipping Terms:
Minimum Order Quantity: 1 sqm
Price: Negotiable
Packaging Details: Plastic bag inside on one roll and carton case outside or cut into small piece and plastic bag.
Delivery Time: 5-10days
Payment Terms: D/A, L/C, D/P, T/T, Western Union, ，Trade assurance,Paypal
Supply Ability: 3000meters per week
Contact Now
Detailed Product Description
Material: Monofilament Polyester Mesh/inch: 40-600mesh/inch
Hole Shape: Square Weave Way: Plain Weave
Used: Printing Sample: Free
High Light:

screen printing mesh roll

,

monofilament polyester mesh

Plain Weave 165T Polyester Screen Printing Mesh For Screen Printing









1.Description



  1. Mesh count: 6T~165T
  2. Material: 100% polyester monofilament
  3.  Weave type: Plain
  4. Color: white, Yellow, black
  5.  Width: 42",45",50",53",57",62",65",74",86",90",120",130",width available (width as order will be ok also)
  6. Standard length: 30m/roll,50m/roll. (Cut length as order will be also available)
  7. Theoretical ink: 6.5-128 cm3/m2



2.Application



Credit Cards 150T/380-31;120T/300-34;100T/255-34;71T/180-55
Dashboards 165T/420-31;150T/380-31;140T/355-31;120T/300-34;110T/280-34um;90T/230-48;36T/90-100
Ceramic Tiles 165T/420-31;150T/380-31;140T/355-31;120T/300-34;100T/255-40;77T/195-55;62T/160-64;
43T/110-80;36T/90-100;32T/83-100;12T/30-150
Glass 165T/420-31;150T/380-31;140T/355-31;120T/300-34;100T/255-40;90T/230-48;77T/195-48;
62T/160-64;68T/175-55;43T/110-80;
Textiles 150T/380-31;140T/355-31;120T/300-34;100T/255-40;77T/195-48;62T/160-64;54T/137-64;
47T/120-55;43T/110-80;40T/100-80;36T/90-100;32T/83-100;16T/40-200;12T/30-150
Objects 165T/420-31;150T/380-31;140T/355-31;120T/300-34;100T/255-40



3 Specification





COUNT (INCH) COUNT (CM) DIAMETER (UM) OPEPING (UM) OPEN AREA(%) THICKNESS(UM) VOLUME (CM³/CM²) MAX TEN SION(N/CM)
15 6 400 1270 64 720 460 30-60
18 7 350 1078 64 640 410 30-60
20 8 300 950 58 550 319 30-60
25 10 250 750 56 620 347 30-60
30 12 250 583 49 450 220 30-60
30 12 150 683 67 300 201 30-60
40 16 200 425 46 400 184 30-60
50 20 80 420 71 120 85 35-37
50 20 150 350 49 260 127 30-60
60 24 100 316 58 136 78 35-40
60 24 120 297 50 240 120 35-60
73 29 120 225 43 240 103 35-60
80 32 64 248 63 95 59 30-34
80 32 100 212 46 200 92 35-40
85 34 100 195 44 221 97 35-40
90 36 100 178 41 216 88 35-40
100 39 55 200 61 88 53 25-30
100 39 80 176 47 150 70 35-37
110 43 80 153 43 130 56 35-37
120 47 55 158 55 88 48 25-30
120 47 71 142 44 135 59 30-34
135 53 55 133 50 86 43 25-30
135 53 64 125 44 100 44 26-31
150 59 64 105 38 100 38 26-31
160 64 55 101 42 98 41 25-30
160 64 64 92 35 120 42 30-34
180 72 48 91 43 78 66 27-29
180 72 55 84 37 100 37 25-30
200 80 48 77 38 74 28 27-29
195 77 55 75 33 105 34 25-30
230 90 48 63 33 85 28 27-29
250 100 40 60 36 70 25 20-24
280 110 40 51 31 85 26 20-24
305 120 40 43 27 68 18 20-24
355 140 34 37 27 58 15 22-24
380 150 31 36 29 46 13 21-23
420 165 31 30 24 46 11 21-23
460 180 27 28 26 56 14 20-22



4.Feature advantage

  • Any ink deposits and any ink system are possible with screen printing,so silk screen printing mesh is widely used to print knitted fabric,blankets,silk even coarse denim.
  • Screen printing offers many superiorities of ink transparency,ink briliance,various decorative pattern choice,and fast production cycle time,so silk screen printing mesh is perferred for CDs and DVDs printing process.
  • Silk screen printing mesh is also used for glass printing,such as pharmacy glass appliance,home appliance( microwaves oven), Automotive glass(black mask for the front,side and back windows),glass containers(perfumes,cosmetics,drink bottles).
  • Silk screen printing mesh is the fastest and most economical method to print printed circuit boards(PCB)solder masks,etching resist,legends and single or multi-layers.

Plain Weave 165T Polyester Screen Printing Mesh For Screen Printing 0
