Chemical Industry 316 Stainless Steel Filter Wire Mesh 120 200 300 400 500 600 Micron

Certification
China Anping County Comesh Filter Co.,Ltd certification
China Anping County Comesh Filter Co.,Ltd certification
Customer Reviews
Never appear quality problem, timely delivery, very satisfied.

—— Eric

Money and treasures will be plentiful

—— Yee

Integrity enterprises, quality assurance, timely delivery, first-class after-sale.

—— Mario

I'm Online Chat Now

Chemical Industry 316 Stainless Steel Filter Wire Mesh 120 200 300 400 500 600 Micron

Chemical Industry 316 Stainless Steel Filter Wire Mesh 120 200 300 400 500 600 Micron
Chemical Industry 316 Stainless Steel Filter Wire Mesh 120 200 300 400 500 600 Micron Chemical Industry 316 Stainless Steel Filter Wire Mesh 120 200 300 400 500 600 Micron Chemical Industry 316 Stainless Steel Filter Wire Mesh 120 200 300 400 500 600 Micron Chemical Industry 316 Stainless Steel Filter Wire Mesh 120 200 300 400 500 600 Micron

Large Image :  Chemical Industry 316 Stainless Steel Filter Wire Mesh 120 200 300 400 500 600 Micron

Product Details:

Place of Origin: China
Brand Name: COMESH
Certification: FDA
Model Number: CO-Hel

Payment & Shipping Terms:

Minimum Order Quantity: 30meter
Price: negotiable
Packaging Details: plywood case
Delivery Time: 7-10 days
Payment Terms: L/C, T/T
Supply Ability: 3000 meters per month
Detailed Product Description
Material: Stainless Steel 304,316,316L Roll Size: 30meter Per Roll In Length,1.02m Or 1.22m In Width
Application: Filtering,protection,arts And Crafts And So On Features: Corrosion Resistant,heat Resistant
Certificate: FDA Opening Size: 1micron To 3000micron
High Light:

crimped wire mesh

,

stainless steel mesh cloth

  chemical industry 120 200 300 400 500 600 micron 316 stainless steel filter wire mesh





stainless steel mesh fulfill a variety of functions. Routinely incorporated in signs, railing infills, cabinet inserts,

plant screens, and in other applications



Features of stainless steel woven wire mesh:

Wire Mesh has the strength to perform in industrial settings, the aesthetics to enhance architectural designs, and the

versatility to fulfill a variety of functions



304 SS displays good oxidation resistance to a temperature of approximately 1600°F in intermittent service and to a

temperature of 1700°F in continuous service



non-magnetic in the annealed condition



From a cost standpoint, it is usually the most attractively priced of most readily available stainless steel mesh

alloys in the industry, especially when taking into consideration its lifecycle.



Specifications:



Stainless Steel Plain / twill weave wire mesh
Mesh/inch Wire diameter Aperture Open area(%) Weight(KG/㎡)
inch mm inch mm
1 0.080 2.03 0.920 23.37 92.0 2.00
2 0.063 1.60 0.437 11.10 87.4 2.50
3 0.054 1.37 0.279 7.09 83.8 2.70
4 0.047 1.20 0.203 5.16 81.2 2.70
5 0.041 1.04 0.159 4.01 79.5 2.60
10 0.024 0.60 0.076 19.4 74.9 1.80
12 0.020 0.50 0.064 1.62 75.9 1.50
14 0.020 0.50 0.052 1.314 71.9 1.75
16 0.018 0.45 0.045 1.137 71.2 1.60
18 0.016 0.40 0.040 1.01 69.4 1.40
20 0.009 0.24 0.040 1.03 76.0 0.57
20 0.012 0.30 0.038 0.970 72.2 0.90
30 0.012 0.30 0.0215 0.547 63.9 1.35
30 0.0094 0.24 0.0243 0.620 72.1 0.84
40 0.0098 0.25 0.015 0.385 36.74 1.25
50 0.0079 0.20 0.0121 0.308 36.7 1.00
60 0.0047 0.12 0.012 0.303 71.6 0.42
60 0.0059 0.15 0.0107 0.273 64.5 0.65
80 0.0047 0.12 0.0078 0.198 38.7 0.58
80 0.0055 0.14 0.0069 0.177 45.5 0.76
100 0.0039 0.10 0.006 0.154 59.8 0.50
100 0.0043 0.11 0.0056 0.144 55.1 0.60
120 0.0027 0.07 0.0056 0.142 67.7 0.29
120 0.0031 0.08 0.0052 0.132 38.7 0.38
150 0.0024 0.06 0.0043 0.109 41.6 0.27
165 0.0018 0.045 0.0043 0.109 50 0.167
180 0.0019 0.05 0.0036 0.091 64.5 0.22
180 0.0023 0.06 0.0032 0.081 57.4 0.32
200 0.0019 0.05 0.003 0.077 60.6 0.24
200 0.0024 0.06 0.0026 0.067 52.7 0.35
250 0.0012 0.03 0.0028 0.072 49.8 0.11
250 0.0016 0.04 0.0024 0.062 36.9 0.20
270 0.0014 0.035 0.0023 0.059 60 0.16
270 0.0016 0.04 0.0021 0.054 57.4 0.21
300 0.0012 0.03 0.0022 0.055 57 0.13
325 0.0014 0.035 0.0017 0.043 55.3 0.20
400 0.0012 0.03 0.0013 0.034 52.7 0.18
500 0.0009 0.025 0.001 0.025 50.7 0.15
635 0.0007 0.020 0.0008 0.020 55.0 0.10







Applications of wire mesh stainless steel:



Farm, Garden, and Agricultural Use
Archeology
Around the House
Aviary and Bird Screen
Beekeeping
Decorative Applications
Fencing, Caging, and Enclosures
Filtration and Separation
Fireplace Screen
Food Processing and Preparation
Heat Treating
Infill Panels
Refinery and Oil Field
Window and Safety Guards
Security and Correctional Facility
Insect Screen



Chemical Industry 316 Stainless Steel Filter Wire Mesh 120 200 300 400 500 600 Micron 0



Our company:



Founded in 1987,COMESH is a professional manufacturer of polyester mesh,stainless steel mesh and wire mesh belt.Our factory is located in Anping County-the famous Wire Mesh Land of China,with a land area of 40,000 square meters,a construction area of 13,000 square meters.PFM factory has 83 sets P7100&P7150 Sulzer polyester printing mesh weaving looms,23 sets Sweden Texo polyester dryer fabric looms,50 sets Japanese GRS1300 wire mesh looms,and 46 sets of other machine and devices including automatic warp arranging machine,heat setting machine,Austria Automatic seaming machine and other test facilities.
