Dutch Stainless Steel Wire Mesh Belt 72x15 Mesh For Extruder

Dutch Stainless Steel Wire Mesh Belt 72x15 Mesh For Extruder
Dutch Stainless Steel Wire Mesh Belt 72x15 Mesh For Extruder

Large Image :  Dutch Stainless Steel Wire Mesh Belt 72x15 Mesh For Extruder

Product Details:
Place of Origin: CHina
Brand Name: COMESH
Certification: SGS
Model Number: CO-Hel
Payment & Shipping Terms:
Minimum Order Quantity: 1 roll
Price: negotiable
Packaging Details: waterproof paper inside,plywood case outside
Delivery Time: in 7 working days
Payment Terms: T/T
Supply Ability: 2000 rolls per month
Detailed Product Description
Name: Stainless Steel Dutch Wire Mesh Belt For Extruder,72X15 Mesh Usage: Aotu Filter Screen Mesh
Material: Ss 304 Or 201 Width: MAX 400mm
High Light:

crimped wire mesh

,

stainless steel mesh cloth

stainless steel Dutch wire mesh belt for extruder,72X15 mesh







Wire mesh extruder screen filters are extensively used in the extrusion of plastic profiles. Applications include UPVC window profiles, plastic tubing ranging from gutters to industrial utility pipes and custom made extrusions,and many more other industry.



larger count of wires is found in the warp and the smaller count in the shute, thus reversing the method used in plain dutch weave,
twilled dutch weaves





Reverse Dutch weave wire cloth is woven using two sizes of wire. Smaller wires are used in the warp direction and are woven with a larger shute wire. The smaller wires are woven tightly together, providing a tight mesh for filtering. The larger wire provides strength to the mesh. The primary uses of this wire cloth are filtration and separation of liquid and slurry products.







Appplications of ss 304 or 201 extruder screen wire mesh for plastic recycle :



mainly used in filtering of plastic wire drawing bench,wire drawing machine,coating machine,such as plastic bags,plastic film and so on.







Specifications of ss 304 or 201 extruder screen wire mesh for plastic recycle:





Mesh/inch Wire Dia.(mm) Width(mm) Length/Roll(m)
72/15 0.45/0.55 97---400 10/20
120/15 0.35/0.45 97---400 10/20
132/17 0.32/0.45 97---400 10/20
150/17 0.3/0.45 97---400 10/20
152/24 0.27/0.4 97---400 10/20
152/30 0.27/0.4 97-400 10/20
170/17 0.27/0.45 97-400 10/20
180/18 0.27/0.45 97-400 10/20
200/40 0.17/0.27 97---400 10/20
260/40 0.15/0.25 97---400 10/20





Features of ss 304 or 201 extruder screen wire mesh for plastic recycle:



Resistant to abrasion
Durability
Sturdiness
Plain/Twill weave stainless steel wire mesh has good performance at acid-resisting, alkali-resisting and anticorrosion.
High strength, good tensiontoughness and abrasion performance, durable in use.







reverse Dutch Twilled Weave mesh:
each weft wire goes through two warp wires alternatively.
The Reverse Dutch Twill Weave allows to use wires
with larger diameters and gives better stability and
strenght to the weft.



reverse Plain dutch weave mesh
it has more and finer warp wires and fewer and heavier weft wires, giving high stability and good performance









sample  and packing:



samples extruder screen mesh can be supplied for testing.



Dutch Stainless Steel Wire Mesh Belt 72x15 Mesh For Extruder 0
